Coriollis mass flow meter

Name: Coriollis mass flow meter
Brand: DEEWAN EQUIPMENTS & INSTRUMENTS
Price: 290000.0 INR
Availability: InStock

Price 290000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Coriollis mass flow meter Specification

Protection
IP65, optional IP67/IP68

Diameter
DN15 to DN200

Pressure Range
Up to 32 MPa

Sensor Type
Dual tube, Coriolis principle

Resolution
0.01 kg/h

Equipment Type
Coriolis Mass Flow Meter

Current Range
4-20 mA output

Temperature Range
-50C to +200C

Capacity
Up to 5000 kg/h depending on model

Measurement Range
0.1 kg/h to 5000 kg/h

Frequency
50/60 Hz

Application Media
Liquids, gases, slurries

Connectivity Type
4-20mA, RS485 MODBUS, HART

Humidity %
0-95% RH, non-condensing

Flow Rate
0-5000 kg/h (model dependent)

Material
Stainless steel 316L

Power Supply
24V DC, optional 220V AC

Power Consumption
<20W

Accuracy
0.1% of reading

Display Type
Digital LCD, backlit

Range
0-5000 kg/h

Installation Orientation
Any, horizontal or vertical

Density Measurement
Yes, integrated

Ex Certification
Optional for hazardous area

Repeatability
0.05% of reading

Electronics Enclosure
IP65/IP67, separate or compact

Alarm Function
High/low flow, temperature, density

Viscosity Measurement
Optional feature

Zero Stability
0.01 kg/h

Housing Material
Aluminum alloy or stainless steel

Output Signal
Pulse, analog, communication port

Process Connection
Flange, threaded, hygienic clamp available

Coriollis mass flow meter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
1 Piece Per Week

Delivery Time
4 Week

Sample Available
No

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
wooden box

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO

About Coriollis mass flow meter

Deewan Enterprises is a leading supplier specializing in all types of industrial flow meters and related measurement products. With years of expertise and commitment to quality, we cater to a wide range of industries including oil and gas, water management, chemical processing, pharmaceuticals, and more. Our comprehensive product portfolio includes electromagnetic, turbine, ultrasonic, positive displacement, and mass flow meters, designed to ensure precise and reliable fluid measurement for diverse applications.

At Deewan Enterprises, we understand the critical role that accurate flow measurement plays in optimizing operational efficiency, ensuring safety, and complying with regulatory standards. Thats why we offer only the highest quality products from globally recognized manufacturers. Our team of experienced professionals is dedicated to providing tailored solutions, from product selection and installation to maintenance and support.

Advanced Measurement Technology

Based on the Coriolis principle with dual tube sensors, this flow meter delivers accurate real-time monitoring of mass flow, density, and temperature. Its integrated digital LCD display supports user-friendly operation, while optional advanced features like viscosity measurement further extend its utility in precision engineering and process control environments.

Versatile Installation and Connectivity

Offering flange, threaded, or hygienic clamp process connections as well as compact or separate electronics, the Coriolis flow meter can be fitted in any orientation-horizontal or vertical. Its compatibility with communication protocols including 4-20mA, RS485 MODBUS, and HART ensures seamless integration into diverse automation systems.

Robustness for Industrial Environments

Constructed from stainless steel 316L and providing IP65 to optional IP68 protection, the meter withstands challenging process conditions, high pressures (up to 32 MPa), and a broad temperature range (-50C to +200C). Ex certification is available for hazardous area installation, ensuring operational safety.

FAQ's of Coriollis mass flow meter:

Q: How is the Coriolis mass flow meter installed and can it be oriented in any direction?

A: Yes, the Coriolis mass flow meter is designed for flexible installation. It can be mounted in any orientation-horizontal or vertical-thanks to its advanced sensor design. This adaptability helps simplify the installation process in complex pipe systems.

Q: What are the main benefits of using this flow meter for industrial applications in India?

A: Key advantages include high measurement accuracy (0.1% of reading), repeatability (0.05%), broad media compatibility (liquids, gases, slurries), robust stainless steel 316L construction, multiple output options, and optional Ex certification for hazardous zones. These features support precise and safe operations in various Indian industries.

Q: When should I opt for optional features such as viscosity measurement or Ex certification?

A: Viscosity measurement becomes essential when monitoring complex or multi-phase fluids where viscosity impacts process efficiency. Ex certification is recommended when installing the meter in hazardous areas with potential exposure to explosive atmospheres, ensuring compliance and workplace safety.

Q: Where can this Coriolis flow meter be applied, and what process connections are available?

A: It is suitable for chemical, pharmaceutical, food, energy, and oil & gas industries across India. You can choose from flange, threaded, or hygienic clamp connections, making it easy to match existing pipeline standards and application needs.

Q: What is the process for integrating the meter with an existing control system?

A: Integration is straightforward, as the meter supports analog (4-20 mA), digital (RS485 MODBUS), pulse, and HART communication. The device can be configured through its backlit LCD display or remotely, and is compatible with common industrial automation platforms.

Q: How does the alarm function enhance operational safety?

A: The meter's alarm function alerts users to high or low flow, temperature, or density changes in real time. This proactive monitoring allows for swift interventions, minimizing the risk of process interruptions or equipment damage.

Q: What usage guidelines ensure optimal performance and longevity?

A: For best results, select the appropriate measurement range and process connection during installation. Regular calibration, adherence to specified power (24V DC or 220V AC), and environmental operating limits (temperature, humidity, pressure) will maintain accuracy and extend service life.
